Promotion!!! HW230L Hydraulic Drilling Rig
Drilling diameter: 75-325mm
Drilling depth: 230m
Rated Power: 15Kw
Watch Product Video
  • PRODUCT DESCRIPTION
  • TECHNICAL PARAMETERS

Best Promotion Only from 2020.10.01 to 2020.10.30, with amazing FOB Price US$14,300 .

HW230L Hydraulic Drilling Rig

  • 1.This drilling rig use the automatic telescopic drilling tower,supported by two high strength cylinder.and a set of Hydraulic valve control the drilling tower up and down.The operation is saving of time and labor, safety and reliable,to maximize create the benefits for users.

  • 2.The Chassis use the Rubber tracks,Lighter weight can reduce the voice from the vehicle moving,and reduce the vehicle body vibration,then can reduce the fuel consumption.it can walk on the city road and dosen’t hurt the road

  • 3.The Chassis comes with hydraulic legs,can use for rig leveling,loading and unloading,it can also can be used as ancillary support when machine working4、24Ve1ectric-start diesel engine reduces the operator's labor intensity.

  • 4.It use the 24v electric start diesel engine, reducing the operator's labor intensity, especially in the cold season, when diesel engine difficult to start, it showed a great advantage.

  • 5.The machine supporting Bw-160 mud pump,the flow and lift of pump is big,and easy maintenance,the spare parts can easy purchase in all over the country

  • 6.Customer can choose to add the screw pipe machine(75-168mm),Improve work efficiency and reduce labor costs

  • 7.We have model HW-160L/HW-190L/HW-230L can choose


(Machine parameter)

(Model)

HW-230L

Drilling depth(m)

230

Open hole dia. (mm)

500, 273

End hole dia. (mm)

75

Drill rod dia. (mm)

42, 50, 60

drill angle (° )

90-75

Matching engine power (kW)

15

Weight without power (kg)

3600


Dimension L*W*H(m)

3.8*1. 95*2. 7

(Spindle)

Speed (r/min)

64/128/287/557

Stroke (mm)

450


(Crawler chassis)

Crawler size (mm)

350*90*48

Climbing angle (° )

20°

Moving speed (km/h)

10

(mm)
Hydraulic leg valid height

1300

(Drill tower)

Rated load (ton)

18

Height (m)

6.5

(Mud pump)

Flow (L/min)

160

Max. pressure (MPa)

1.3

Reciprocating times/min

165


Inlet hose dia. (mm)

51

Outlet hose dia. (mm)

32
